Description of the device
Features
The Pixel Bar 12 is a LED system from Showtec.
• 3-in-1 RGB LED's
• Linkable
• Multiple DMX modes for total control
• Built in programs
• IEC Power in and output
• DMX In and DMX Out (3-pole)
• LCD Display with menu buttons (Mode, Setup, Up and Down)
• Output: Lumens : 1380
Lux @2m: 3430
Max Distance: 15m
• Light Source: LED System: 12 x RGB 3-in-1 3W LEDs
• Drive Current: 350mA
• Refresh rate: 140Hz
• Power Supply: AC 100-240V 50/60 Hz
• Peak Power 143 Watt
• Continuous Power 110 Watt
• DMX controllable
• DMX channels: 3, 4, 6, 7, 9, 12, 18, 36
• Built-in sound to light function for standalone applications
• Optical system
• Dimmer: 0-100%
• Strobe: 0-11 Hz
• Beam Angle: 40°
• Dimensions: 1015 x 175 x 74 mm incl bracket
• Weight: 4,28 kg
• Housing: Aluminum
NOTE: Knowledge of DMX is required to fully utilize this unit.
Overview
1 2
Fig. 1
1) Adjustment Screw + Mountingbracket for Truss mounting
2) 12 x RGB 3-in-1 3W LEDs
