General| Latency | 2.9 ms |
|---|---|
| Number of Channels | 4 |
| Audio Frequency Response | 20 Hz to 20 kHz |
| RF Sensitivity | -98 dBm at 10-5 BER |
| Power Requirements | 100 to 240 V AC, 50–60 Hz |
| Type | Digital Quad-Channel Wireless Receiver |
| Modulation | Shure proprietary digital |
| Spurious Rejection | > 80 dB |
| Image Rejection | > 80 dB |
| Audio Output | XLR |
| Network Interface | Ethernet 10/100 Mbps |
| Operating Temperature Range | -18°C (0°F) to +50°C (122°F) |
| Dynamic Range | 120 dB (A-weighted) |
