Shure AD4Q User Manual

Configuration
Transformer Coupled Balanced (1=ground, 2=audio +, 3=audio
−)
XLR
Transformer Coupled Balanced (Tip = Audio +, Ring = Audio -,
Sleeve = Ground)
TRS
Impedance
100 Ω, Typical, XLR Line Out
Full Scale Output (200K Ωload)
+18 dBVLINE setting
−12 dBVMIC setting
+8 dBVTRS
Mic/Line Switch
30 dB pad
Phantom Power Protection
Yes
Dimensions
44 x 483 x 333 mm H x W x D
Weight
4.8 kg (10.6 lbs), without antennas
Housing
Steel; Extruded aluminum
Power Requirements
100 to 240 V AC, 50-60 Hz, 0.68 A max.
Thermal Power Dissipation
31 W (106 BTU/hr)Maximum
21 W (72 BTU/hr)Idle
DC Power Requirements
10.5 to 32V DC4.0 A max.
Network Interface
10/100 Mbps, 1Gbps, Dante Digital Audio
Network Addressing Capability
DHCP or Manual IP address
Maximum Cable Length
100 m (328 ft)
Cascade Output
Connector Type
BNC
2
2
Note: For connection of one additional receiver in the same band
Shure IncorporatedAD4Q Digital Quad Receiver
19/212017/10/25

Shure AD4Q Specifications

General

Latency	2.9 ms
Number of Channels	4
Audio Frequency Response	20 Hz to 20 kHz
RF Sensitivity	-98 dBm at 10-5 BER
Power Requirements	100 to 240 V AC, 50–60 Hz
Type	Digital Quad-Channel Wireless Receiver
Modulation	Shure proprietary digital
Spurious Rejection	> 80 dB
Image Rejection	> 80 dB
Audio Output	XLR
Network Interface	Ethernet 10/100 Mbps
Operating Temperature Range	-18°C (0°F) to +50°C (122°F)
Dynamic Range	120 dB (A-weighted)
