Shure GLXD6 - Resetting the Transmitter; Specifications

Shure Incorporated
28/33
•
Resetting the Transmitter
Restores the transmitter to the following factory settings:
Controls = unlocked
Press and hold the transmitter link button while turning on the transmitter until power LED goes off.
When the link button is released, the transmitter will automatically initiate linking to find an available receiver. Press the link but
ton on an available receiver to relink.
Specifications
Tuning Bandwidth
2400–2483.5 MHz
Working Range
Indoor
Up to 30 m (100 ft) typical , Up to 60 m
(200 ft) maximum
Outdoor
Up to 20 m (65 ft) typical , Up to 50 m (165 ft)
maximum
Transmit Mode
Shure proprietary digital
Audio Frequency Response
20 Hz
– 20 kHz
Dynamic Range
120 dB, A-weighted
RF Sensitivity
-88 dBm, typical
Total Harmonic Distortion
0.2%, typical
RF Output Power
10
mW E.I.R.P. max
Operating Temperature Range
-18°C (0°F) to 57°C (135°F)
