Multiple Ethernet Switch Setup #2
Each networked device needs an individual connection to the switch.
AXT620 with front panel
DHCP switch set to
ON
Server
Client
Ethernet Switch
AXT610 ShowLink Access Point
Multiple Ethernet Switch (Wi-Fi) Setup #3
Each networked device needs an individual connection to the switch.
Wi-Fi Router (DHCP enabled)
Server
Client
Client
AXT620 with front panel
DHCP switch set to OFF
AXT620 with front panel DHCP switch set to OFF
AXT610 ShowLink Access Point
