Shure PGX Wireless Quick Start Guide

10
PGX4
Dimensions
40mmX181mmX104mm(HxWxD)
Weight
327g(11.5oz.)
Housing
ABS
Sensitivity
-105dBmfor12dBSINAD,typical
Image Rejection
>70 dB, typical
Power Requirements
12–18VDC@150mA,suppliedbyexternalpowersupply(tippositive)
Configuration
Impedance balanced
Audio Output Level
Ref.±33kHzdeviation,1kHztone
XLR connector:
–19dBV(into600Ωload)
6.35 mm (1/4”) connector:
–5dBV(into3kΩload)
Impedance XLR connector:
200Ω
6.35 mm (1/4”) connector:
1kΩ
Pin Assignments XLR connector:
1=ground,2=hot,3=cold
6.35 mm (1/4”) connector:
Tip=audio, Ring=no audio,
Sleeve=ground
Frequency Range and Transmitter Output Level
Band Range Output
Power
H6 524 to 542 MHz 30mW
J6 572.250to590.875MHz 30mW
K5E 606to630MHz 10mW
L5 644to662MHz 30mW
P6 702.200to719MHz 30mW
R1 800to820MHz 20mW
T1 846to865MHz 10mW
Q8 740 to 752 MHz 10mW
JB 806to810MHz 10mW
R14 794to806MHz 20mW
R19 794to806MHz 10mW
X5 925to932MHz 10mW
G4 470.125to493.825MHz 30mW
G8 494.200to509.825MHz 30mW
Q24 736to754MHz 30mW
NOTE:
ThisRadioequipmentisintendedforuseinmusical
professionalentertainmentandsimilarapplications.
ThisRadioapparatusmaybecapableofoperatingonsome
frequenciesnotauthorizedinyourregion.Pleasecontact
yournationalauthoritytoobtaininformationonauthorized
frequenciesandRFpowerlevelsforwirelessmicrophone
products.
