Shure PGX Wireless Quick Start Guide

9
PGX
Working Range
LineofSight
100m(300ft)
Note:ActualrangedependsonRFsignalabsorption,
reflectionandinterference.
Audio Frequency Response
45–15000 Hz
Note:Dependentonmicrophonetype
Total Harmonic Distortion
Ref.±33kHzdeviation,1kHztone
0.5%, typical
Dynamic Range
>100 dB, A-weighted
Operating Temperature Range
-18°C(0°F)–+50°C(122°F)
Note:Batterycharacteristicsmaylimitthisrange.
Transmitter Audio Polarity
Positive pressure on microphone diaphragm (or positive
voltageappliedtotipofWA302phoneplug)produces
positivevoltageonpin2(withrespecttopin3oflow-
impedanceoutput)andthetipofthehighimpedance
1/4-inch output.
PGX1
Audio Input Level gain position
mic:
−10dBVmaximum
0dB:
+10dBV maximum
–10dB:
+20dBV maximum
Gain Adjustment Range
30dB
Input Impedance
1MΩ
RF Output Power
10–30mW
varies by region
Pin Assignments
TA4M
1:ground(cableshield)
2:+5VBias
3:audio
4:Tiedthroughactiveloadtoground(Oninstrumentadaptercable,pin4floats)
Dimensions
108mmx64mmx19mm(HxWxD)
Weight
81g(3oz.),withoutbatteries
Housing
Molded polycarbonate case
Power Requirements
2“AA”sizealkalineorrechargeablebatteries
Battery Life
upto8hours(alkaline)
PGX2
Audio Input Level at –10 dB gain setting:
+2dBV maximum
at 0 dB gain setting:
–8dBVmaximum
Gain Adjustment Range
10 dB
RF Output Power
10–30mW
varies by region
Dimensions
254 mm X 51 mm dia. (10 X 2 in.)
Weight
81g(10.2oz.)(withoutbatteries)
Housing
Molded PC/ABS handle and battery cup
Power Requirements
2“AA”sizealkalineorrechargeablebatteries
Battery Life
upto8hours(alkaline)
Specifications

Shure PGX Wireless Specifications

General

Brand	Shure
Model	PGX Wireless
Category	Microphone system
Language	English
