PGX WIRELESS FREQUENCY AND CHANNEL GUIDE
H6: 524.000—542.000 MHz
CH
GROUP
0 1 2 3 4 5 6 7 8 9
1
524.250 524.525 524.175 524.225 525.850 525.925 525.500 525.450 524.125 524.650
2
527.350 527.625 525.650 525.700 528.600 528.675 527.800 527.750 525.600 525.850
3
529.425 529.700 526.775 526.825 530.300 530.375 531.700 531.650 526.725 527.950
4
530.900 531.175 528.425 528.475 531.700 531.775 533.825 533.775 528.375 529.750
5
533.275 533.550 529.725 529.775 532.800 532.875 536.275 536.225 529.675 536.325
6
535.050 535.325 532.175 532.225 534.350 534.425 537.575 537.525 536.250 537.625
7
538.300 538.575 534.300 534.350 535.600 535.675 539.225 539.175 538.050 539.275
8
539.500 539.775 538.200 538.250 539.200 539.275 540.350 540.300 540.150 540.400
9
541.125 541.400 540.500 540.550 541.525 541.600 541.825 541.775 541.350 541.875
Fullrange.Even
distribution in US
TVchannels23,24,
and 25
Fullrange.Max#of
frequenciesinUS
TVchannel23.
Fullrange.Max#of
frequenciesinUS
TV channel 24.
Fullrange.Max#of
frequenciesinUS
TV channel 25.
Full range. Max #
offrequenciesin
USTVchannels23
and 25.
J6: 572.250—589.875 MHz
CH
GROUP
0 1 2 3 4 5 6 7 8 9
1
572.250 572.525 572.175 572.225 573.850 573.925 573.500 573.450 572.125 572.650
2
575.350 575.625 573.650 573.700 576.600 576.675 575.800 575.750 573.600 573.850
3
577.425 577.700 574.775 574.825 578.300 578.375 579.700 579.650 574.725 575.950
4
578.900 579.175 576.425 576.475 579.700 579.775 581.825 581.775 576.375 577.750
5
581.275 581.550 577.725 577.775 580.800 580.875 584.275 584.225 577.675 584.325
6
583.050 583.325 580.175 580.225 582.350 582.425 585.575 585.525 584.250 585.625
7
586.300 586.575 582.300 582.350 583.600 583.675 587.225 587.175 586.050 587.275
8
587.500 587.775 586.200 586.250 587.200 587.275 588.350 588.300 588.150 588.400
9
589.125 589.400 588.500 588.550 589.525 589.600 589.825 589.775 589.350 589.875
Fullrange.Even
distribution in US
TVchannels31,32,
and33.
Fullrange.Max#of
frequenciesinUS
TVchannel31.
Fullrange.Max#of
frequenciesinUS
TVchannel32.
Fullrange.Max#of
frequenciesinUS
TVchannel33.
Full range. Max #
offrequenciesin
USTVchannels31
and33.
L5: 644.000—662.000 MHz
CH
GROUP
0 1 2 3 4 5 6 7 8 9
1
644.250 644.525 644.175 644.225 645.850 645.925 645.500 645.450 644.125 644.650
2
647.350 647.625 645.650 645.700 648.600 648.675 647.800 647.750 645.600 645.850
3
649.425 649.700 646.775 646.825 650.300 650.375 651.700 651.650 646.725 647.950
4
650.900 651.175 648.425 648.475 651.700 651.775 653.825 653.775 648.375 649.750
5
653.275 653.550 649.725 649.775 652.800 652.875 656.275 656.225 649.675 656.325
6
655.050 655.325 652.175 652.225 654.350 654.425 657.575 657.525 656.250 657.625
7
658.300 658.575 654.300 654.350 655.600 655.675 659.225 659.175 658.050 659.275
8
659.500 659.775 658.200 658.250 659.200 659.275 660.350 660.300 660.150 660.400
9
661.125 661.400 660.500 660.550 661.525 661.600 661.825 661.775 661.350 661.875
Fullrange.Even
distribution in US
TVchannels43,
44, and 45.
Full range. Max #
offrequenciesin
USTVchannel43
Full range. Max #
offrequenciesin
US TV channel
44.
Fullrange.Max#of
frequenciesinUS
TV channel 45.
Full range. Max #
offrequenciesin
USTVchannels43
and 45.
