T1: 846.000—865.000 MHz
CH
GROUP
0 1 2 3 4 5 6 7 8 9
1
847.500 846.100 863.200 846.800 854.200 855.475 855.075 854.750 854.750 854.425
2
848.600 847.350 863.900 848.425 855.300 857.425 857.775 855.850 855.850 855.525
3
850.100 849.400 864.500 850.425 856.700 860.600 860.725 857.250 857.250 857.400
4
852.100 851.800 852.875 857.800 858.350 858.350 858.500
5
853.300 853.200 855.650 859.675 860.225 860.225 859.900
6
855.100 856.775 860.775 861.325 861.325 861.000
7
857.200 859.725
8
858.650 861.550
9
859.800 864.800
Compatible setup
forusewithEUT-
VR, -VS and -VT
Compatible
setupforusewith
EUT-TW,-TX,-TY
and -TZ
European
harmonizedband:
optimizedfor863-
865MHz
Full Range max. #
ofcompatiblefre-
quencies(sameas
SLX-S6,group3)
BEL/TUR
preferred:opt.TV
ch.69854-862MHz
U.K.preferred:
“CH69Coordi-
nated”SET1
U.K.preferred:
“CH69Coordi-
nated”SET3
U.K.preferred:“Co-
ordinatedfrequen-
cies”INDOORS
U.K.preferred:“Co-
ordinatedfrequen-
cies”OUTDOORS
(option 1)
U.K.preferred:“Co-
ordinatedfrequen-
cies”OUTDOORS
(option 2)
Q8: 740.000—752.000 MHz
CH
GROUP
0 1 2 3
1
740.125 740.125 740.125 740.125
2
741.500 741.950 741.225 740.800
3
743.375 743.500 742.925 741.825
4
744.600 745.675 745.425 743.075
5
746.325 747.400 746.875 745.125
6
748.500 748.625 748.925 746.575
7
750.050 750.500 750.175 749.075
8
751.875 751.875 751.200 750.775
9
751.875 751.875
Full Range Full Range Full Range Full Range
R14 and R19: 794.000–806.000
CH 0 CH FREQ. CH FREQ. CH FREQ.
1 795.150 1 794.375 1 794.100 1 794.900
2 798.100 2 797.425 2 795.300 2 796.100
3 802.200 3 803.025 3 798.550 3 799.350
4 805.350 4 804.475 4 802.150 4 802.950
5 803.350 5 804.150
6 804.925 6 805.725
Full Range Full Range Full Range Full Range
JB: 806.000—810.000
CH 1 2 3 4 5 6
1
806.250 806.375 806.125 806.500 806.125 806.250
2
807.500 808.625 807.375 807.375 807.375 807.250
3
809.625 809.750 809.500 808.625 808.375 808.500
4
-- -- -- 809.625 809.750 809.375
Full range Full range Full range Full range Full range
