Shuttle MVP - Attaching the Backrest Extension Pad; Replacing Backrest; Inspect Rebound Elastic

Page 15
ATTACHING THE BACKREST EXTENSION PAD
STEP 10
ITEMS REQUIRED
Backrest Extension Pad
1. The backrest extension pad can either be used as an extension of the padded center on the carriage (supports deep
squats) or as an alternative low profile headrest (Pic 10.1). To use an extension, fit into the space at the foot-end of the
carriage (Pic 10.2). When performing single-leg exercises you may remove the extension pad from the foot-end of the
carriage and use the exposed area as a footrest for the uninvolved foot.
10.1
10.2
ASSEMBLY OF THE MVP (STEP 10)
