3. PREVENTIVE MAINTENANCE
If you want to keep your machine in a good working condition, it is necessary to do the
following actions :
- clean the stylus pin guide and the stylus assembly regularly
- avoid dust and abrasive particles on the guiding and driving elements
How to clean the stylus pin guide and the stylus assembly
- Unplug the marking machine
- Unscrew the stylus pin guide (see General layout of the stylus assembly in
appendix)
- Remove the stylus, the spring and the core
- Clean all parts and remove the grease
- Lubricate the stylus and the stylus pin guide using exclusively the oil supplied
with your maintenance kit.
- Reassemble the machine and manually fasten the stylus pin guide
Note : please pay attention to the direction when reassembling the core (see General
layout of the stylus assembly in appendix)
