NOTI143US - R00.doc Translation of the original instructions 6/25
INSTALLATION AND START-UP
1.
UNPACKING
Except if we deliver the system, it is generally supplied in an appropriate packaging,
which needs to be kept for any return of the material.
Remove the sub-systems carefully (controller, control handbox, possible options …) from
their packages.
2.
INSTALLATION
2.1. Fastening
Column-type machines
o Install the machine on a rigid and stable support frame
o After installing the entire marking machine, fasten the base with 2 M10
screws.
Integrated-type machines
o Install the machine on a rigid and stable support frame
o Fasten the marking head onto the machine by complying with the
indications of the integration plan, available thread length 12 mm max.
Portable-type machines
o No fastening : marking gun designed to be held manually
Note : The integrated and portable type machines are designed to function in all
positions (vertical, horizontal, stylus towards the bottom or the top)
The machine should only be lifted by the column and the
base ; it should never be lifted by the head housing.
Weight of the machine: 33 kg
