SICK C4000 Advanced Ex User Manual

Figure 1: Mount the safety light curtain in the explosion-proof enclosure
1
2
Figure 2: Align the safety light curtain in the explosion-proof enclosure
1
Measure the distance from the end of the cover to the first rib.
2
Detailed view
MOUNTING 3
8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex
11
Subject to change without notice

SICK C4000 Advanced Ex Specifications

General

Enclosure rating	IP65, IP67
Wavelength	950 nm
Operating Voltage	24 V DC
Type	Safety Light Curtain
Resolution	14 mm, 30 mm
Scanning range	0 m ... 7 m
Supply voltage	24 V DC
Ambient operating temperature	-10 °C ... +55 °C (depending on the type)
Light Source	LED
Storage Temperature	-25 °C ... +70 °C
