7 Technical data
7.1 Data sheet
NOTE
T
he following table only contains details on the safety light curtain that are not included
in the underlying operating instructions.
Table 2: General system data
Minimum Typical Maximum
Protective field height, depending on
t
ype
600, 900, and 1,200mm
Resolution (detection capability) 30mm
Protective field width 0m … 16m
1)
Enclosure rating (EN 60529) IP66
2)
Equipment group/category II
X II 2 G Ex db IIB T6 Gb
X II 2 D Ex tb IIIC T56°C Db
Weight Depending on the protective field height, see "Table of
weights", page 25
1)
If you are using the full protective field width, check to see if the orange LED lights up (cleaning or
ali
gnment necessary). The system still has a reserve of 30%.
2)
In order to achieve enclosure rating IP 66, washers must be used for the fixing screws on the enclosure
cover.
7.2 Table of weights
Table 3: Weight of sender and receiver
Protective field height [mm] Weight [kg]
1)
s S
ender r Receiver
600 28.51 28.54
900 36.54 36.57
1200 44.55 44.58
1)
Tolerance: ± 50 g.
TECHNICAL DATA 7
8017027/1DVD/2023-04-28 | SICK O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex
25
Subject to change without notice

SICK C4000 Advanced Ex Specifications

General

Enclosure rating	IP65, IP67
Wavelength	950 nm
Operating Voltage	24 V DC
Type	Safety Light Curtain
Resolution	14 mm, 30 mm
Scanning range	0 m ... 7 m
Supply voltage	24 V DC
Ambient operating temperature	-10 °C ... +55 °C (depending on the type)
Light Source	LED
Storage Temperature	-25 °C ... +70 °C
