SICK C4000 Advanced Ex User Manual

6,4
9,5
67,5
58,7
161,8
89,6
44,5
1.700,2
1.668,2
1.635
237,7 206,9
50,8
142,1
Figure 19: Dimensional drawing, sender and receiver, protective field height 1,200mm
7 T
ECHNICAL DATA
28
O P E R A T I N G I N S T R U C T I O N S | C4000 Advanced Ex 8017027/1DVD/2023-04-28 | SICK
Subject to change without notice

SICK C4000 Advanced Ex Specifications

General

Enclosure rating	IP65, IP67
Wavelength	950 nm
Operating Voltage	24 V DC
Type	Safety Light Curtain
Resolution	14 mm, 30 mm
Scanning range	0 m ... 7 m
Supply voltage	24 V DC
Ambient operating temperature	-10 °C ... +55 °C (depending on the type)
Light Source	LED
Storage Temperature	-25 °C ... +70 °C
