SICK CDB620 User Manual

CDB620-101
16.3
(0.64)
19.3
(0.76)
16.3
(0.64)
16.3
(0.64)
55.9 (2.20)
22.9
(0.90)
18.3
(0.72)
19.8
(0.78)
16.8
(0.66)
25
(0.98)
1
(0.04)
16.8 (0.66)
54.9 (2.16)
1 432 2
Figure 9: Device dimensions; unit mm (inch), decimal separator: point
1
5-pin M12 male connector
2
Cable gland
3
5-pin M12 female connector
4
D-Sub female connector
CDB620-201
16.3
(0.64)
19.3
(0.76)
16.3
(0.64)
16.3
(0.64)
22.9
(0.90)
18.3
(0.72)
19.8
(0.78)
16.8
(0.66)
25
(0.98)
1
(0.04)
16.8 (0.66)
54.9 (2.16)
1
2
31.1
(1.22)
24.9
(0.98)
15
(0.60)
Figure 10: Device dimensions; unit mm (inch), decimal separator: point
1
Cable gland
2
D-Sub female connector
TECHNICAL DATA 9
8021690/ZZN1/2021-05-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CDB620
23
Subject to change without notice

SICK CDB620 Specifications

General

Brand	SICK
Model	CDB620
Category	Control Unit
Language	English
