Type CDB620-001 (no. 1042256), CDB620-101 (no.
1042257), CDB620-201 (no. 1042258)
Rel. Air humidity Max. 90 %, non-condensing
1)
At terminals U
IN
.
2)
For voltage U
IN
*, switched via S 1 and internal fuse.
3)
Valid with corresponding device identification on the type label.
4)
When using the SICK sensor standard connection cable.
Enclosure rating not tested by UL.
UL certified when using one of the following power supply units: UL60950-1: LPS or Class 2 (UL1310),
UL508: Class 2 (UL1310)
5)
Ambient operating temperature 0 °C to –35 °C under the following conditions:
•
Mounting, electrical connection as well as configuration or power-up of the module via built-in
switches only in the normal ambient operating temperature range 0 °C to +40 °C.
•
Use at ambient operating temperature 0 °C to –35 °C only when at rest (no mounting, connection,
or configuration work on the module).
9.1 Dimensional drawing
Power
Sensor 1
Sensor 2
Aux In 1
Aux In 2
Result 1
Result 2
Aux Out 1
Aux Out 2
113.1 (4.45)
53.9 (2.12)
18
(0.71)
7.8
(0.31)
87.3 (3.44)
1
(0.04)
105.7 (4.16)
100 (3.94)
124.2 (4.89)
58.7 (2.31)
24.86
(0.98)
22.45 (0.88)
13
(0.51)
4.5
(0.18)
8.3 (0.32)
10.3 (0.40)
99.6 (3.92)
120.2 (4.73)
64 (2.52)
8.1
(0.32)
12
(0.47)
Ø
3
(Ø
0.12
)
1
Figure 7: Device dimensions; unit mm (inch), decimal separator: point
CDB620-001
16.3
(0.64)
19.3
(0.76)
16.3
(0.64)
16.3
(0.64)
55.9 (2.20)
22.9
(0.90)
18.3
(0.72)
19.8
(0.78)
16.8
(0.66)
25
(0.98)
1
(0.04)
16.8 (0.66)
54.9 (2.16)
1 2
Figure 8: Device dimensions; unit mm (inch), decimal separator: point
1
Cable gland
2
D-Sub female connector
9 TECHNICAL DATA
22
O P E R A T I N G I N S T R U C T I O N S | CDB620 8021690/ZZN1/2021-05-07 | SICK
Subject to change without notice
