9 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/CDB
Please note: This documentation may contain further technical data.
Type CDB650-204 (part no. 1064114)
Optical indicators 11 x LED
Electrical connections 1 x 17-pin M12 female connector, A-coded
1 x internal 9-pin D-Sub male connector
Spring-loaded terminals:
•
8 for 0.14 mm
2
... 2.5 mm
2
wires
•
29 for 0.14 mm
2
... 1 mm
2
wires
Cable glands 5 x M16, clamping range 4.5 ... 10 (7) mm
Supply voltage DC 10 V ... 30 V
SELV according to EN 61010 and Class 2 (UL 1310)
Power consumption 1 W
Input current Max. 2.4 A
1)
Fuse
2)
MINI blade fuse, 32 V, 2 A
Housing Polycarbonate
Trigger unit Control current: 10 mA, switching current: see "Connect‐
ing an external illumination unit for the Lector65x",
page 18
Mark of conformity CE, UL
3)
Electrical safety IEC 61010-1:2010 + Cor.: 2011
Protection class III
Enclosure rating IP65
4)
(EN 60529/A1: 2002-02)
EMC test EN 61000-6-2: 2005-08 EN 61000-6-3: 2007-01
Vibration resistance EN 60068-2-6: 2008-02
Shock resistance EN 60068-2-27: 2009-05
Weight Approx. 265 g
Ambient temperature Operation: –40 °C ... +50 °C
5)
Warehouse: –30 °C ... +75 °C
Rel. Air humidity Max. 90 %, non-condensing
1)
At terminals U
IN
.
2)
For voltage U
IN
*, switched via S 1 and internal fuse.
3)
Valid with corresponding device identification on the type label.
4)
When using the SICK sensor standard connection cable.
Enclosure rating not tested by UL.
UL certified when using one of the following power supply units: UL60950-1: LPS or Class 2 (UL1310),
UL508: Class 2 (UL1310)
5)
Ambient operating temperature 0 °C to –35 °C under the following conditions:
•
Mounting, electrical connection as well as configuration or power-up of the module via built-in
switches only in the normal ambient operating temperature range 0 °C to +40 °C.
•
Use at ambient operating temperature 0 °C to –35 °C only when at rest (no mounting, connection,
or configuration work on the module).
9 TECHNICAL DATA
22
O P E R A T I N G I N S T R U C T I O N S | CDB650 8021689/ZZN2/2021-05-07 | SICK
Subject to change without notice
