9.1 Dimensional drawing
113.1 (4.45)
7.8
(0.31)
87.3 (3.44)
18
(0.71)
1
(0.04)
53.9 (2.12)
8.3
(0.33)
105.7 (4.16)
10.3
(0.41)
58.7 (2.31)
124.2 (4.89)
4.5
(0.18)
Figure 7: Device dimensions; unit mm (inch), decimal separator: point
1
Female connector M12, 17-pin
2
ø 4.5 mm ... 10 mm PG connector (5 x)
