SICK D 35 Series User Manual

IO-Link interface
46 © SICK AG • Subject to change without notice • 8014868/YIF1/2020-10-19
9.3.4 SICK-specic–teach
Index
decimal
(hex)
Description Format Access Value range Example Remarks
130 (0x82) TEACH UINT16 W • 0: Q1 DtO (Q1 dis-
tance to object)
• 1: Q2 DtO (Q2 dis-
tance to object)
• 2: Q1 near
• 3: Q1 far
• 4: Q1 center
• 5: Q2 near
• 6: Q2 far
• 7: Q2 center
• 8: Q1 ObSB (Q1
object between
sensor and back-
ground)
• 9: Q2 ObSB (Q2
object between
sensor and back-
ground)
• 10: Q2 4 mA
• 11: Q2 20 mA
• 12: Q2 0 V
• 13: Q2 10 V
• 14: Q2 Analog
center
• 15: Fine teach
+10 mm
• 16: Fine teach
-10 mm
A teach overwrites
a function that has
already been set with
a newly selected func-
tion. For values that
are not taught in again
and for an unsuccess-
ful teach, the old value
is retained.
1) SICK-specic service data – teach
