SICK D 35 Series User Manual

8014868/YIF1/2020-10-19 • © SICK AG • Subject to change without notice 47
IO-Link interface
9.3.5 SICK-specic–processdata
Index
decimal
(hex)
Description Format Access Value range Example Remarks
83 (0x53) Process data
structure
UINT8 R/W • 0: Dis-
tance+Q1+Q2
• 1: Distance+OWS
+alarm
• 2:
Level+OWS+alarm
• 3: Distance
• 4: Distance+
signal quality
• 5: Timer (only for
Extended version)
• 6: Timer+Q1+Q2
(only Extended
version)
3
→ Page 39, Chap-
ter 9.2.
105 (0x69) Process data
resolution
UINT8 R/W • 0: 0.1 mm
• 1: 1 mm
• 2: 10 mm
Resolution distance
measured value for the
process data (IO-Link
only)
107 (0x6B) Process data stan-
dardization
UINT16 R/W • 0 … 50,000 mm Move process data
zero point in 1 mm
steps.
Table 16: SICK-specic service data – process data
9.3.6 SICK-specic–othersettings
Index
decimal
(hex)
Description Format Access Value range Example Remarks
81 (0x51) Multifunctional
input MF function
UINT8 R/W • 0: Teach
(teach-in)
• 1: Laser on/o
• 2: MF OFF
(MF deactivated)
1
99 (0x63) Multifunctional
input MF level
(bit 0)
Multifunctional
input MF teach
conrmation on
Q1 (bit 1)
Record R/W Bit 0:
• 0: Low active
• 1:Highactive
Bit 1:
• 0:Inactive
• 1: Active
→ See Chapter 10.6
on page 53
