Table 5: System connection pin assignment (male connector, M12, 5-pin)
Pin Wire color
1)
s S
ender r Receiver
1 Brown +24VDC (voltage supply
in
put)
+24VDC (voltage supply
input)
2 White Reserved OSSD1 (output signal
switching device 1)
3 Blue 0VDC (voltage supply
input)
0VDC (voltage supply
input)
4 Black Reserved OSSD2 (output signal
switching device 2)
5 Gray Not connected Not connected
1)
Applies to the connecting cables recommended as accessories.
Further topics
•
"Int
egration in electrical control", page 23
6.3 System connection via connection cable (M12, 5-pin to 8-pin)
An optional connection cable is available to connect the 5-pin system connection to
an e
xisting 8-pin female connector. The connection cable can be used to replace an
existing TGS safety light curtain with a deTec4 Core Vibes, without having to route new
cables.
6 ELE
CTRICAL INSTALLATION
40
O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/1GWF/2022-11-11 | SICK
Subject to change without notice

SICK deTec4 C4C-EV03030A10000 Specifications

General

Cable length	3 m
Conductor cross-section	0.25 mm²
Locking type	Screw locking
Shielding	Shielded
Drag chain use	Suitable for drag chain use
Ambient operating temperature flexible use	-5 °C ... +80 °C
