SICK deTec4 C4C-EV03030A10000 User Manual

Minimum Typical Maximum
Length of cable for connecting
c
ables
1)
"Length of cable", page 54
Ambient operating temperature
2)

3)
 -30°C +55°C
Air humidity (non-condensing) 15% 95%
Storage temperature -30°C +70°C
Housing cross-section 31mm × 34mm, plus bracket, see "Dimensional dr
aw‐
ings", page 55
Vibration resistance
4)
5…150Hz, 3,5mm/1g (EN 60068-2-6)
Shock resistance
5)
15g/6ms (EN 60068-2-27)
Class 3M4 (IEC TR 60721-4-3)
1)
Maximum permissible conductor resistance must be observed.
2)
The temperature difference between sender and receiver must not exceed 25K.
3)
The cable belonging to the device incl. the associated connection plug must not be flexibly mounted
under –25°C
.
4)
Test conditions per axis: 1octave/minute, 20 sweeps.
In addition to the required swept-sine tests according to IEC61496-1, the safety light curtain was
subjected to additional tests.
The devices have passed the following tests according to EN60068-2-6 without modifications:
•
10Hz…200Hz: 20g in each axis
•
200Hz…400Hz: 15g in each axis
•
200Hz…2kHz (broadband noise): 10g for 8h in each axis
5)
Test conditions per axis: 200shocks.
The shock resistance tests were also passed under the following test conditions: 10g, 16ms, 1,000
shocks per axis.
In addition to the tests according to IEC60068-2-27, the safety light curtain was subjected to additional
continuous shock tests. The devices passed tests with 1,000,000shocks and an acceleration of 30g as
well as tests with 100,000shocks and an acceleration of 100g without any modifications.
12.2 Response time
Table 13: Response time dependent on the protective field height
Protective field height in mm Response time in ms
300 10
450 10
600 10
750 11
900 11
1050 11
1200 12
1350 12
1500 13
1650 13
1800 13
1950 14
2100 14
TECHNICAL DATA 12
8024467/1GWF/2022-11-11 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes
53
Subject to change without notice

SICK deTec4 C4C-EV03030A10000 Specifications

General

Cable length	3 m
Conductor cross-section	0.25 mm²
Locking type	Screw locking
Shielding	Shielded
Drag chain use	Suitable for drag chain use
Ambient operating temperature flexible use	-5 °C ... +80 °C
