12.3 Power consumption
Table 14: Power consumption for sender and receiver
Protective field height in mm Typical power consumption for
sender in W
Typical power consumption for
r
eceiver in W
1)
Resolution 30mm Resolution 30mm
300 0.82 1.63
450 0.86 1.73
600 0.91 1.82
750 0.96 1.92
900 1.01 2.02
1050 1.06 2.11
1200 1.10 2.21
1350 1.15 2.30
1500 1.20 2.40
1650 1.25 2.50
1800 1.30 2.59
1950 1.34 2.69
2100 1.39 2.78
1)
Power discharged again via the OSSDs depending on the connected OSSD load must be added to the
t
able values.
12.4 Length of cable
Table 15: Maximum lengths of cable for wire cross-section 0.34mm
2
, c
opper wire
Single system
Separate connecting cables for
sender and r
eceiver
r
s
b c
S
r
s
b ≤85m c ≤15m
S Control cabinet with safety relay or safety controller
12.5 Table of weights
Table 16: Weight of sender and receiver
Protective field height in mm Weight in g
1)
s S
ender r Receiver
300 290 300
450 430 440
600 570 580
750 700 710
900 840 850
1050 970 980
1200 1110 1120
1350 1240 1250
1500 1380 1390
12 TECHNICAL DATA
54
O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/1GWF/2022-11-11 | SICK
Subject to change without notice

SICK deTec4 C4C-EV03030A10000 Specifications

General

Cable length	3 m
Conductor cross-section	0.25 mm²
Locking type	Screw locking
Shielding	Shielded
Drag chain use	Suitable for drag chain use
Ambient operating temperature flexible use	-5 °C ... +80 °C
