8024019/AE00/V1-0/2019-02| SICK A D D E N D U M T O O P E R A T I N G I N S T R U C T I O N S | FWE200DH
Subject to change without notice
PRODUCT DESCRIPTION 2
Fig. 3: Pressure regulator
2.2.3 Heated extraction hose
The heated extraction hose serves to preheat the sample gas when, for example, the
heater temperature or surface temperature in the thermal cyclone has to be reduced due to
the application. Furthermore, this prevents the sample gas cooling down between the sam-
ple gas probe and measuring system.
Fig. 4: Heated extraction hose
Control valve for setting the purging pressure
Pressure indicator for purging pressure
Water connection G¼ inch
Water filter with drain nozzle
