SICK ICD890 User Manual

Figure 7: Variant A connection mask
Figure 8: Variant B connection mask
“ETHERNET 1 ... 3” connections
1
7
2
6
54
3
8
Figure 9: Female connector, M12, 8-pin, X-coded
ELECTRICAL INSTALLATION 6
8023775/18IM/2020-07-02 | SICK T E C H N I C A L I N F O R M A T I O N | Camera ICD890 Generation 4
23
Subject to change without notice
