1.2.2 IDM Bluetooth Hand-held Scanners
Type IDM141 IDM161 IDM241 IDM261
Field of
application
General Purpose Industrial General Purpose Industrial
Enclosure rating IP 41 IP 65 IP 41 IP 65
Supported code
types
1D, Stacked
1
1D, Stacked
1
1D, Stacked, 2D 1D, Stacked, 2D
2
Code resolution ≥0.076 mm
1)
≥0.076 mm
1)
≥0.07 mm
1)
, ≥0.13 mm
2)
Reading
distance
(at code
resolution)
20 mm ... 850 mm
(0.5 mm)
1)
20 mm ... 850 mm (0.5
mm)
1)
SR model:
30 mm ... 400 mm (0.25 mm)
2)
Interfaces
USB (Keyboard Wedge & Com Port Emulation), RS-232,
(Ethernet TCP/IP, PROFINET, PROFIBUS, DeviceNet)
3
Bluetooth
Protocol
Bluetooth v 2.1 EDR, 2.4 ... 2.4835 GHz Bluetooth v 4.0, 2.402 … 2.4830 GHz
Bluetooth
operating range
Up to 100 m (free view), Batch function for
expansion of the wireless radius
Up to 100 m (free view), Batch function for
expansion of the wireless radius
Optical
indicators
2 LEDs (good read, charge of battery, radio connection status)
Vibration No Yes No Yes
Acoustic
indicators
Beeper, disengageable
Operating
Voltage
5 V DC (+/- 5%)
Current
consumption
(Operating)
180 mA 230 mA (Vibrator enabled)
180 mA (Vibrator disabled)
750 mA
(charging incl.
base station
750 mA (charging incl.
base station)
Current
consumption
(Standby)
80 mA 80 mA 175 mA 175 mA
Light source LED: visible red light (630 nm)
Laser aimer No Yes (Laser Class 1) No Yes (Laser Class 1)
Ambient
operating
temperature
-10 °C ... 50 °C -20 °C ... 50 °C -10 °C ... 50 °C -20 °C ... 50 °C
Storage
temperature
-40 °C ... 70 °C -30 °C ... 70 °C -40 °C ... 70 °C -40 °C ... 70 °C
1)
Valid for Code 39,
2)
Valid for Data Matrix
For detailed technical specifications, see the Online Data Sheet on the product site on the web
(www.sick.com
).
1
Depending on scanner version (PDF version is necessary).
2
Depending on scanner version, option of low performance DPM Code reading can be enabled via Plug-in.
3
Optional via external SICK connection modules.
