Symbology Reading Control
IDM corded
© SICK AG · Germany · All rights reserved · Subject to change without notice
Family Code Selection P.C. Parameter Selection Option Code
Readable Symbology
CS QR Code */ Micro QR Code * A0
CS Data Matrix * A1
CS Maxi Code A2
CS Aztec Code * A3
CS Chinese Sesible (Han Xin) code A4
CS Australian Post B0
CS British Post B1
CS Intelligent Mail barcode B3
CS Japanese Post B4
CS KIX Post B5
CS Planet Code B6
CS Postnet B8
Above symbologies marked with * are enabled as default. When you select “Auto”, the scanner only reads
those symbologies marked with *.
"Popular 1D" includes "Code 128", "GSA-128", "UPC-A", "UPC-E", "EAN-13", "EAN-
8", "Codabar/NW-7", "Code 39", " Interleaved 2 of 5", "Code 93", "GS1 DataBar
(RSS-14)".
When you set the minimum and maximum length of each symbology, please note the data length of the
scanned bar code doesn’t include start/stop characters.
To Next Page
