Programming Procedures
Operating Instructions
IDM corded
& IDM Bluetooth
28
© SICK AG · Germany · All rights reserved · Subject to change without notice
8017159/142O/2019-05-23
3.2.2 System List & Master Default
3.2.3 Single Scan
Scan
„M_DEFAULT
The scanner will recover all
programmable parameters into
factory preset configurations and
then issue the completion beeping.
The scanner will list the product
information and revision number to
host via selected host interface,
then issue the completion beeping.
Scan
„SYSLIST“
Scan one of family
codes
Scan
„PROGRAM“
Scan one of option
codes
Repeat
selection
Scan
„END“
Yes
No
Enter Programming mode.
Select the desired programming
family.
Select one option code for the desired
parameter.
Do you want to select another
programming family?
Exit programming mode.
