SICK Lector620 User Manual

8014640/YWI5/2016-08-08 • Subject to change without notice • SICK AG • Waldkirch • Germany • www.sick.com 7LECTOR62X | SICK
Overview of all interfaces and connection options
“Ethernet”
(HOST 2, reading result,
image transfer)
In
put 2
(e.g. encoder
, teach-in matchcode)
In
put 1
(e.g.
external reading trigger)
Output
1
(e.g. indicat
or lamp)
Output
2
(e.g. trig
ger for external illumination)
Lector
®
620
e.g. cable no. 2055419 (2 m)
“Serial RS-232/422” (HOST 1), reading result alternative to Ethernet
CDB620-001
SerialSerial
e.g. cable
no. 6034414 (2 m)
Configuration
Image displa
y
Diagnostics
SOPASSOPAS
SerialSerial
“Power/Serial Data/
CAN/I/O”
(AUX 1, HOST 1)
no. 1042256
...
...
1
2
DC 10 V ... 30 V
GND
HOST
PC
Further data
processing
e.g.cable no. 2014054 (2 m)
“Serial RS-232” (AUX 1)
“Ethernet” (AUX 2,
image transfer)
“USB” (AUX 3, image transfer)
DC 10 V ... 30
V
In
puts/outputs = digital
A
dditional external inputs and
outputs via CMC600 parame
ter
cloning module
e.g. cable
no. 6036106 (2 m)
alternative for configuration, without image display
alternative for configuration and image display
switching inputs and outputs if required
EthernetEthernet
USBUSB
Fig. 12: Lector62x Professional, High Speed, DPM Plus, OCR with swivel connector
In
put 2
(e.g. encoder
, teach-in matchcode)
In
put 1
(e.g.
external reading trigger)
Output
1
(e.g. indicat
or lamp)
Output
2
(e.g. trig
ger for external illumination)
Lector
®
620 ECO
e. g. cable no. 2055419 (2 m)
“Serial RS-232/422” (HOST), reading result
CDB620-001
SerialSerial
Configuration
Image display
Diagnostics
SOPASSOPAS
SerialSerial
“Power/Serial Data/CAN/I/O”
(AUX 1, HOST)
no. 1042256
...
...
1
2
DC 10 V... 30 V
GND
HOST
PC
Further data
processing
e.g. cable no. 2014054 (2 m)
“Serial RS-232” (AUX 1)
”USB” (AUX 2, image transfer)
DC 10 V ... 30
V
In
puts/outputs = digital
A
dditional external inputs and
outputs via CMC600 parame
ter
cloning module
e.g. cable no. 6036106 (2 m)
alternative for configuration, without image display
switching inputs and outputs if required
USBUSB
Fig. 13: Lector62x ECO with cable outlet
Type code
I C R 6 2 0 x – x x x x x x
1 2 3 4 5 6 7 8 9 10 11 12 13
Position
Description
1 … 5 Product family
ICR62 Lector62x
6 Image sensor resolution
0 752 px x 480 px (WVGA)
7 Model
C OCR
D DPM Plus
E ECO
H High Speed
S Professional
8 Focus
H Adjustable focus
(only ECO variant)
T Teach auto focus
9 Image orientation, focal distance of the
lens
0 Imagers unlike housing shape,
7 mm working distance
3 Imagers like housing shape,
11.7 mm working distance
5 Imagers like housing shape,
18.6 mm working distance
10 Illumination
1 Blue + Red
2 Red
6 Infra-red
7 Blue
11 Communication (Host)
0 Serial, USB and Ethernet
1 Serial and USB
12 IP protection class
3 IP 65
4 IP 67
1) - See “Pin assignment overview” on page 8.
Information Relating to UL60950 Certication
The certication is only valid with corresponding de-
vice identication on the type label of the code reader.
LISTED
I.T.E.
E244281
P/N: 1050589
S/N: 1101 0001
DC 10-30V 3W Imax=1,7A
D-79276 Reute
Made In Germany
MAC 00:06:77:05:2E:11
Manufactured: January 2011
ICR620S-T11503
LECTOR
620
®
Fig. 11: Type label example
• Type: ICR62xx-xxxxxx
• Supply voltage: DC 10 V ... 30 V
• Power consumption: 3 W
