Table 5: Second display level
Display LED Color Status
Test
O
Blue Test (reading diagnostics) selected
Ö
Blue Test started
Teach
O
Blue Teach-in selected (default: Match code)
Ö
Blue Teach-in started
O
Green Teach-in successful
O
Red Teach-in unsuccessful (match code default setting:
Unable to teach in any code)
Setup
O
Blue Set-up selected
Ö
Blue Set-up started
O
Green Set-up successfully quit
O
Yellow Set-up partially successful (in at least one of the
3 parameter modules)
O
Red Setup unsuccessful
O = illuminated; Ö = flashing
Functions
Table 6: Function overview
Function Description
Test (read diagnostics) Percentage analysis: The device records a series of images and uses
the current reading performance settings to decode them. With the
0 ... 100% bar graph, the device shows the read rate of the last 10%
(90% to 100%).
The bar graph display is activated in standard read mode.
Teach When you teach in a match code, the device reads the code that is pre‐
sented and saves the code permanently as a target code for future
code comparisons during read mode. For Pharmacodes, the Code type &
code length function must first be defined in SOPAS ET.
Setup The device adjusts itself automatically to suit the lighting conditions,
working distance, and quality of the code presented. The device perma‐
nently stores the acquired values as per the default setting.
PROFINET operation (single port)
The Ready status LED signals the device status in the PROFINET network.
Table 7: Device status in the PROFINET network (first display level, Ready status LED)
Ready LED Device status Remarks
Green com‐
ponents
Red compo‐
nents
O o
Device is ready for use.
PRODUCT DESCRIPTION 3
8018071/16XD/2020-05-06 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector63x Flex C-mount and S-mount
19
Subject to change without notice
