5 Integration and commissioning of the NAV-LOC in a vehicle
8023450/2018-12-17| SICK OPERATING INSTRUCTIONS | NAV-LOC
9
Subject to change without notice
5 Integration and commissioning of the NAV-LOC in a
vehicle
5.1 Connecting the NAV310 voltage supply
Connecting the voltage supply for the NAV310 is described in detail in the operating instructions (BA-
NAV310en_8016534) in chapter 5. Here is a short summary:
Supply voltage:
24 V DC ± 15% acc. to IEC 60364441
(observe permissible lengths of cable in table 11 on page 33 of the BANAV310en_8016534 manual)
The NAV310 consumes the following:
• Maximum 36 W when switching on without wired switching outputs
• Typically 12 W during operation, additional maximum 12 W with wired switching output
The voltage supply/the external power supply unit for voltage supply must be able to continuously
provide at least 40 W, or continuously provide at least 48 W when the switching output is wired.
Connections of the NAV310
Pin assignment of the “Power” connection on the NAV310
For example, a cable with a length of 5 m with part number 6043440 and open ends is available for
supplying the NAV310; it can be shortened if necessary.
