Other sensors can be integrated via IO-Link, for example for distance and height meas‐
uring purposes.
Fieldbus and Ethernet interfaces with OPC-UA and MQTT provide data preprocessed in
“dual talk” (edge computing) for the controller and for cloud computing. In addition, the
SIM can be integrated into a SICK CAN sensor network.
Thanks to the high-performance multi-core processor and a highly synchronous FPGA
I/O module, the SIM2000 can be used for fast image/sensor data processing and
handling of input and output signals in real time.
The SICK AppSpace open software platforms enable tailor-made application programs
to be developed for demanding applications.
The HMI and data visualization features can be provided on any browser-enabled
notebook, PC, or tablet. The app is created using the SICK AppStudio SDKs and - when
using HALCON - using HDevelop from MVTec.
2D-cameras
Sick 3D-cameras
Illumination
Sick detection and ranging sensors
SICK CSN
Trigger, I/Os,
Fast Encoder
Dual Port Fieldbus
Power, Dig-I/O
IoT Gateway
µSD card
HMI/Viewer
PLC
(in preparation)
OPC-UA
MQTT
SIM2x00
3.3 SICK AppSpace
Detailed instructions on the SICK AppStudio as well as programming the device can be
found at supportportal.sick.com.
3.4 Preset Ethernet interfaces
NOTE
Preset IP addresses of the ETHERNET interfaces:
•
ETHERNET 1: 192.168.0.1
•
ETHERNET 2: 192.168.1.1
•
ETHERNET 3: 192.168.2.1
•
ETHERNET 4: 192.168.3.1
3 PRODUCT DESCRIPTION
12
O P E R A T I N G I N S T R U C T I O N S | SIM2000 8023297//2021-06-22 | SICK
Subject to change without notice
