5. COMMISSIONING, OPERATION
5.7 Overview of parameters
Menu item Description Parameter Factory setting
SP1 / SP2
Hysteresis function:
Switching point (switching device 1 / 2)
0.25 ... 100% of the measuring range Nominal pressure
FH1 / FH2
Window function:
Window High (switching output 1 / 2)
0.25 ... 100% of the measuring range Nominal pressure
RP1 / RP2
Hysteresis function, reset switching
point, switching output (1, possibly 2)
0 ... (switching point – 0.25% of the
measuring range)
Nominal pressure – 10%
FL1 / FL2
Window function: Window Low switching
output (1, possibly 2)
0 ... (Window High – 0.25% of the measuring
range)
Nominal pressure – 10%
EF Extended programming functions
RES
Resetting of the set parameters back to
the factory settings
Yes / No
DS1 / DS2
Switching delay time which must not
be interrupted until an electrical signal
switch takes place (SP1, possibly SP2)
0.00 ... 65.00 s 0.00 s
DR1 / DR2
Reset switching delay time which must
not be interrupted until an electrical
signal switch takes place (RP1, possibly
RP2)
0.00 ... 65.00 s 0.00 s
OU1 / OU2
Switching function (switching output
1 / 2)
HNO = Hysteresis function, normally open
HNC = Hysteresis function, normally closed
FNO = Window function, normally open
FNC = Window function, normally closed
HNO
OU3 Output signal switchover
I = 4 ... 20 mA
U = DC 0 ... 10 V
I
POL1 / POL2 Switching logic (switching output 1 / 2) PNP, NPN PNP
ALOW
Measuring range scaling/Turn down
(analog value, start value)
Corresponding analog output
Measuring range
beginning
AHGH
Measuring range scaling/Turn down
(analog value, end value)
Corresponding analog output Measuring range end
