Operating Instructions PBS
Parameter Description
SP1 / SP2 Hysteresisfunction:SwitchpointSwitchoutput(1or2)
FH1 / FH2 Windowfunction:Windowhighswitchoutput(1or2)
RP1 / RP2 Hysteresisfunction:Resetpointswitchoutput(1or2)
FL1 / FL2 Windowfunction:WindowLowswitchoutput(1or2)
EF Enhanced Programme Functions
RES Return the set parameter to the Factory Settings
DS1
SwitchDelayTime,whichmustoccurwithoutinterruptionbeforeanyelectricalsignalchangeoccurs(Q1or
Q2)
DS2
DR1
Switch Delay Time, which must occur without interruption before any electrical signal change occurs (RP1
or RP2)
DR2
OU1 Switching Function Switching Output (1 or 2)
OU2 HNO = Hysteresis Function, normally open
HNC = Hysteresis Function, normally closed
FNO = Window Function, normally open
FNC = Window Function, normally closed
UNIT Changing Units
(If the pressure range is higher than the display range, no change of the unit is posssible
and the parameter UNIT is not shown)
Operating Modes
Systemstart  -Displayisfullyactivatedfor2s
- When the pressure switch is powered up within the range of the
    hysteresis,theoutputswitchissetto„notactive“bydefault
Display Mode - normal operation, displays system pressure
Programming Mode - Setting Parameters
Parameter
4-digit LED display - Display system pressure
- Display Menu Item
- Display Parameter
1. LED (blue) - Status Switch Output 1
2. LED (blue) - Status Switch Output 2 (Optional)
7. Starting, operation
GB
7. Starting, operation
