Parameter Description
0SET Zero Point adjustment (+ 3% of Nominal Pressure)
DISM DisplayvalueinDisplayMode
ACT = Current System Pressure
LOW, HIGH = Minimum, Maximum System Pressure
SP1(FH1), RP1(FL1), SP2(FH2), RP2(FL2), OFF = Display off
DISU Display-Update 1, 2, 5, 10 Updates/Second
DISR Display rotate 180°
RHL CleartheMin-andMax-valuememory
PAS Password input, 0000 = no password
Password input Digit by Digit
TAG Input of a 16-digit alphanumeric Measuring Point number
Error Description
ATT1 On changing the Switch Point the system automatically reduces the Reset Point
ATT2 Zero Point adjustment error, current pressure is outside the limits
ATT3 Password entered for Menu access is incorrect
ERR Internal error
OL Overpressure,measuringrangeexceeded>approx.5%(Displayblinks)
UL Underpressure,undermeasuringrange<approx.5%(Displayblinks)
Error display
Acknowledgement of an Error Display by pressing the „Enter“ key.
value
value
value
value
SP1 / FH1
RP2 / FL2
SP2 / FH2
RP1 / FL1
(Min:LLR  Max:SP1-0.5%) InstrumentNominalPressure - 10%
(Min:LLR+0,5% Max:ULR)  InstrumentNominalPressure
(Min:LLR+0,5% Max:ULR)  InstrumentNominalPressure
(Min:LLR  Max:SP2-0.5%) InstrumentNominalPressure- 10%
Display-Mode
Programming-Mode
Long press on Menu Key
Factory Setting:
Menu (Programming and Factory Setting)
