Subject to change without notice
Safety laser scanners
 


You can nd more connection diagrams at www.mysick.com
S300 Mini Standard with restart interlock and external device monitoring
bn
gn
ye
pk
bu
sh
wh
gy
k2k1
x
x
y
y
z
z
k2
k1
1)
S300 Mini Standard
S1
2
3
4
5
6
7
8
1
K1 K2 H1
k1
k2
sh = shield
+24 V
FE
0 V
• S300 Mini Standard in conjunction with relays/contactors
• Operating mode: with restart interlock (universal I/O 1 must be congured as reset) and external device monitoring
(universal I/O 2 must be congured as EDM)

SICK S300 Specifications

General

Protection Class	IP65
Resolution	30 mm
Interface	RS-422, Ethernet
Power Supply	24 V DC
Operating Temperature	0 °C ... +50 °C
