Subject to change without notice
Safety laser scanners
Electrical data
Connecting cable with round plug connector
250 mm
15 mm
24 V DC (16.8 V DC ... 30 V DC)
≤ 0.25 A (24 V DC)
1)
≤ 1.35 A (24 V DC)
2)
2 –
Static control inputs (with EFI)
External device monitoring (EDM)
Restart/reset
Standby
–
1
3)
1
3)
1
3)
5
4)
–
–
1
4)
Reset required
Safety outputs (OSSD)
Output for warning eld
1
3)
2
2
3)
Depends on the conguration of the
connected EFI device
–
–
–
Transmission rate
RS-232
38.4 kBaud
Transmission rate
Cable length
Galvanized decoupling
–
–
–
≤ 500 kBaud
20 m
5)
–
1)
Without output load.
2)
Including maximum output load.
3)
Availability depends on the conguration of the universal I/Os.
4)
The S300 Mini Remote can only be operated on an S3000/S300 safety laser scanner, on a safety controller Flexi Soft or on a sens:Control device via EFI.
5)
Use only pre-assembled extension cables.
Delivery S300 Mini
• Safety laser scanner
• Operating instructions and CDS (Conguration & Diagnostic Software) on CD-ROM
• Adhesive label “important information”
The extension cable has to be ordered separately!
S300 Mini Standard
2 m S32B-2011BA 1050932
3 m S32B-3011BA 1056430
S300 Mini Remote
2 m S32B-2011EA 1051884
3 m S32B-3011EA 1056431
