Subject to change without notice
Safety laser scanners
 

S300 Mini Remote: protective eld switching with a Flexi Soft safety controller
S1
S2 S3
S4
A1
A B
A2
A
B
A1 I1 X1I6I5I4I3I2
K1 K2 H1
A2 I7 X2Q4Q3Q2Q1I8
H = housing
sh = shield
H
k1
k2
k2k1
x
x
y
y
z
z
k2
k1
1)
FE
Flexi Soft XTIO
FE
Flexi Soft CPU1
2
3
4
5
6
7
1
2
3
4
5
6
7
H
1
wh
bn
gn
ye
gy
pk
bu
sh
bn
gn
ye
pk
bu
sh
wh
gy
S5
FE
0 V
+24 V
S300 Mini Remote
S300 Mini Remote
EFI 2
EFI 1
• Two S300 Mini Remote
• Protective eld evaluation and switching via EFI using a Flexi Soft safety controller

SICK S300 Specifications

General

Protection Class	IP65
Resolution	30 mm
Interface	RS-422, Ethernet
Power Supply	24 V DC
Operating Temperature	0 °C ... +50 °C
