Safety laser scanners
 


Mounting systems
  

  
S300 Mini Standard S300 Mini Remote
Mounting brackets
For rear mounting on
wall or machine
– Mounting kit 1a 2034324
O O
For rear mounting on
wall or machine with
protection of optics
cover
– Mounting kit 1b 2034325
O O
Cross-wise adjustment
possible
Only in conjunction with
mounting kit 1a or 1b
Mounting kit 2 2039302
O O
Mounting plate
Longitudinal adjust-
ment possible
Only in conjunction with
mounting kit 2
Mounting kit 3 2039303
O O
Extension cables
  

  
M12 x 7 Straight
2.5 m DOL-1SS2G2M5E15KM3 6042337 –
O
5 m DOL-1SS2G5M0E15KM3 6042338 –
O
7.5 m DOL-1SS2G7M5E15KM3 6042339 –
O
10 m DOL-1SS2G10ME15KM3 6042340 –
O
15 m DOL-1SS2G15ME15KM3 6042341 –
O
20 m DOL-1SS2G20ME15KM3 6042342 –
O
M12 x 7 + FE
Straight
2.5 m DOL-127SG2M5E25KM0 6020537
O
–
5 m DOL-127SG05ME25KM0 6020354
O
–
7.5 m DOL-127SG7M5E25KM0 6020353
O
–
10 m DOL-127SG10ME25KM0 6020352
O
–
20 m DOL-127SG20ME25KM0 6033096
O
–
Angled
5 m DOL-127SW05ME25KM0 6021342
O
–
7.5 m DOL-127SW7M5E25KM0 6034783
O
–
10 m DOL-127SW10ME25KM0 6035566
O
–
15 m DOL-127SW15ME25KM0 6021343
O
–
Conguration connection cables
 



  
For connecting the conguration connection
to the serial interface on the PC
M8 x 4,
SUB-D
9-pin
2 m DSL-8D04G02M025KM1 6021195
O O
10 m DSL-8D04G10M025KM1 2027649
O O
For connecting the conguration connection to
the USB interface on the PC
M8 x 4,
USB-A
2 m DSL-8U04G02M025KM1 6034574
O O
10 m DSL-8U04G10M025KM1 6034575
O O
Illustration may differ
Conguration connection cable
Connector
RS-232,
USB
35 cm Converter RS-232 to USB 6035396
O O
