12 Annex
12.1 Dimensional drawings
1 Link/Act 2 Link/Act
Dev RDY Funct 3 Funct 2 Funct 1
Mode USB
SIM800
L
ETHERNET 1 ETHERNET 2
INPUT
POWER
SERIAL, I/0
PIN SIGNAL
M12 A / m M12 A / fm
1 DC24 Vin 2 CAN L 3 DC0 Vin 4 CAN H 5 nc
PIN SIGNAL
1 DC24 Vout 2 nc 3 GND 4 IN 5 nc
1 3
4
2
5
1
3
4
2
5
15
610
1115
1
1
38.8 (1.53)
31 (1.22)
4 (0.16)4 (0.16)
36.3 (1.43)
40.7 (1.60)
39.5 (1.56)
24.5 (0.96)
23.5 (0.93)
28.5 (1.12)
49.5 (1.95)
24 (0.94)
14
(0.55)
59.4 (2.34)
207 (8.15)
175.2 (6.90)
192.5 (7.58)
59.4 (2.34)26.2 (1.03) 26.2 (1.03) 31.7 (1.25)
7.1 (0.28)
7.1 (0.28)
Figure 7: Device dimensions, unit: mm (inch), decimal separator: period
1 Elongated drill hole for mounting, for M6 cylinder head screws, max. tightening torque
5Nm
12.2 Licenses
SICK uses open source software which is published by the rights holders under a
free license. Among others, the following license types are used: GNU General Public
License (GPL version2, GPL version3), GNU Lesser General Public License (LGPL), MIT
license, zlib license and licenses derived from the BSD license.
This program is provided for general use without warranty of any kind. This warranty
disclaimer also extends to the implicit assurance of marketability or suitability of the
program for a particular purpose.
More details can be found in the GNU General Public License.
License texts can be read out from the device using a web browser via the following
URL: <device ip>/license/COPYING
Printed copies of the license texts are also available on request.
12 ANNEX
26
O P E R A T I N G I N S T R U C T I O N S | SIM800 8028935//2023-09-26 | SICK
Subject to change without notice
