SICK SIM800 User Manual

6 Electrical installation
6.1 Important information
WARNING
Risk of injury and damage caused by electrical current!
Due to equipotential bonding currents, incorrect earthing can lead to the following
dangers and faults: Voltage is applied to the metal housing, cable fires due to cable
shields heating up, the product and other devices become damaged.
■
Generate the same ground potential at all grounding points.
■
Ground the equipotential bonding via the functional ground connection with a low
impedance.
NOTICE
Device damage due to improper supply voltage!
■
Only operate the device with the specified supply voltage.
■
The voltage supply and all connected signals must meet the requirements for
extra-low voltages with safe separation (SELV) as specified in EN 61010. The
external voltage supply of the device must bridge a brief power outage of 20ms.
■
Only devices that are also supplied with safety extra-low voltage must be con‐
nected.
NOTE
Layout of data cables
■
Use screened data cables with twisted-pair wires.
■
Implement the screening design correctly and completely.
■
To avoid interference, e.g. from switching power supplies, motors, clocked drives,
and contactors, always use cables and layouts that are suitable for EMC.
■
Do not lay cables over long distances in parallel with power supply cables and
motor cables in cable channels.
6.2
Preparing the electrical installation
To carry out the electrical installation, you will need:
•
Connection cables for the peripheral devices, including the corresponding data
sheets
•
Voltage supply cable
•
If customers assemble the cables: crimping tool, ferrules, soldering iron, and other
installation material
ELECTRICAL INSTALLATION 6
8028935//2023-09-26 | SICK O P E R A T I N G I N S T R U C T I O N S | SIM800
15
Subject to change without notice
