SICK TiM55 Series User Manual

à
Marking for the position of the light emission level
á
Ethernet connection, 4-pin M12 female connector
â
Area in which no reflective surfaces are permitted when the device is mounted
ã
Bearing marking to support alignment (90° axis)
ä
270° aperture angle (visual range)
3.3 Display and operating elements
1 2 3
Figure 2: Display and operating elements
1
Red LED (status indicator)
2
Green LED (status indicator)
3
Push-button (no function)
Status indicators
LED (red) LED (green) Description
-
O
Device ready/monitoring mode
Ö
- Fault
- - Device without supply voltage
O = illuminated; Ö = flashing
3.4 Type code
The devices of the product family are arranged according to the following type code:
TIM x y z ‒ aa bb c dd
1 2 3 4 5 6 7 8 9
Table 3: Type code
Position Description Characteristic
1 Device name TIM: Short range 2D-LiDAR sensor
2 Device type 5: Data supplier
3 Performed by 5: 10 m measuring range, 1.0° angular resolution,
performance professional
6: 10 m measuring range, 0.33° angular resolution,
performance professional
7: 25 m measuring range, 0.33° angular resolution,
performance professional, HDDM
8: 25 m measuring range, 0.33° angular resolution,
performance professional, HDDM+
4 Housing 1: Housing IP67 without heating
5 “Empty”: standard
3 PRODUCT DESCRIPTION
12
O P E R A T I N G I N S T R U C T I O N S | TiM55x/56x/57x/58x 8025144//2021-07-21 | SICK
Subject to change without notice
