SICK TiM55 Series User Manual

Working range diagram
0
Scanning range in m (feet) 1
Scanning range in m (feet) 1
Scanning range max.: 10 m (32.81 feet) 2
Scanning range typical (for objects with 10 % remission):
8 m (26.25 feet) 3
180°
‒45°
225°
270°
90°
0°
–6
(–19.69)
6
(19.69)
–2
(–6.56)
2
(6.56)
10
(32.81)
–10
(–32.81)
0–2
(–6.56)
2
(6.56)
–6
(–19.69)
6
(19.69)
–10
(–32.81)
10
(32.81)
Figure 25: TiM55x / TiM56x working range
diagram
1
Sensing range in meters (feet)
2
Maximum sensing range: 10 m
(32.81 feet)
3
Typical sensing range for objects with
10% remission: 8 m (26.25 feet)
Scanning range in m (feet) 1
Scanning range in m (feet) 1
Scanning range max. 25 m (82.02 feet) 2
Scanning range typical (for objects with 10 % remission):
8 m (26.25 feet) 3
180°
‒45°
225°
270°
90°
0°
0 20
(65.62)
–20
(–65.62)
10
(32.81)
–10
(–32.81)
30
(98.43)
–30
(–98.43)
0
20
(65.62)
–20
(–65.62)
10
(32.81)
–10
(–32.81)
30
(98.43)
–30
(–98.43)
Figure 26: TiM57x / TiM58x working range
diagram
1
Sensing range in meters (feet)
2
Maximum sensing range: 25 m
(82.02 feet)
3
Typical sensing range for objects with
10% remission: 8 m (26.25 feet)
10.2 Performance
Variant TiM55x/TiM56x/TiM57x/TiM58x
Response time Typ. 1 scan: 67 ms
Max. 2 scans: 134 ms
1
Detectable object
shape
Almost any
Measurement
errors
Statistical (1 σ): < 20 mm
1
/ < 10 mm
2
Systematic: ± 60 mm
1
Temperature drift: 0.5 mm/K
Integrated appli‐
cation
Measurement data output (radial distance, RSSI signal level, device and
status information, time stamp)
1
Corresponds to max. 134 ms between +45° and +225° of the working range, max. 150 ms between
-45° and +45° of the working range (see "Working range diagram", page 38).
2
Typical value at 90% remission up to maximum sensing range; real value depends on ambient conditions.
3
Only devices with HDDM measurement principle: Typical value at 10% remission up to 6 m sensing
range; real value depends on ambient conditions.
10.3 Interfaces
Variant TiM55x/TiM56x/TiM57x/TiM58x
Ethernet TCP/IP
Max. data transmission rate: 10 Mbit and 100 Mbit
Length of cable: max. 100 m
Digital outputs 1 (PNP, SYNC/Device Ready)
I
out
≤ 100 mA, not electrically isolated from the supply voltage, short-circuit
proof/temperature protected
10 TECHNICAL DATA
38
O P E R A T I N G I N S T R U C T I O N S | TiM55x/56x/57x/58x 8025144//2021-07-21 | SICK
Subject to change without notice
