Variant TiM55x/TiM56x/TiM57x/TiM58x
Optical indicators 2 LEDs (ON, Device Ready)
10.4 Mechanics/electronics
Variant TiM55x/TiM56x/TiM57x/TiM58x
Electrical connec‐
tion
1 x Ethernet connection, 4-pin M12 female connector
1 x “voltage supply/SYNC” connection, 5-pin M12 male connector
1 x micro USB female connector, type B
Supply voltage 9 V DC ... 28 V DC
SELV and PELV acc. to IEC 60364-4-41:2005-12
Power consump‐
tion
4 W (typical)
7 W, with loaded SYNC digital output
Housing Lower part: Aluminum die cast
Optics cover: Polycarbonate with scratch-resistant coating
Housing color Grey (RAL 7032)
Enclosure rating IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013), only valid with closed
“Aux interface” plastic cover
Protection class III (IEC 61140:2016-1)
Weight 250 g without connecting cables
Dimensions (L x
W x H)
60 mm x 60 mm x 86 mm
10.5 Ambient data
Variant TiM55x/TiM56x/TiM57x/TiM58x
Radiance factor 4% ... 1,000% (reflectors)
Electromagnetic
compatibility
(EMC)
Radiation emitted:
Residential area (EN 61000-6-3:2007-01+AMD:A1:2011)
Electromagnetic compatibility:
Industrial environment (EN 61000-6-2:2005)
Vibration resist‐
ance
Sine resonance scan:
10 Hz ... 1,000 Hz
(IEC 60068-2-6:2007)
Sine test:
10 Hz ... 500 Hz; 5 g; 10 frequency cycles
(IEC 60068-2-6:2007)
Noise test:
10 … 250 Hz; 4.24 grms, 5 h
(IEC 60068-2-64:2008)
Shock resistance 50 g; 11 ms; 6 shocks/axis
25 g; 6 ms; 2,000 shocks/axis
50 g; 3 ms ; 10,000 shocks/axis
(IEC 60068-2-27:2008)
Ambient temper‐
ature
Commissioning/switching on: –10 °C ... +50 °C
Operation: –25 °C ... +50 °C
Storage: –40 °C ... +75 °C
(IEC 60068-2-14:2009)
Ambient humid‐
ity
Operation: ≤ 80%, non-condensing
≤ 95%, non-condensing
(EN60068-2-30:2005)
TECHNICAL DATA 10
8025144//2021-07-21 | SICK O P E R A T I N G I N S T R U C T I O N S | TiM55x/56x/57x/58x
39
Subject to change without notice
