SICK TiM55 Series User Manual

Angle (distance values in mm)
Scan 1 2 3 4 5 6 7 8 9 …
1 Output value
(scan 1-4)
0 0 1155 1230 1190 1130 1450 1370 0 …
5 0 0 0 1110 1150 1150 1380 1380 0 …
2. Output value
(scan 2-5)
0 0 1173 1225 1190 1130 1450 1370 0
6 0 0 1200 1210 1190 0 1500 1500 0 …
3. Output value
(scan 3-6)
0 0 1173 1235 1190 1190 1450 1370 0
7 0 730 1150 0 1200 1200 1450 1450 0 …
4. Output value
(4-7)
0 730 1173 1163 1190 1190 1450 1370 0
… … … … … … … … … … …
Individual outliers (shown in bold in the table) influence the average value.
Once the measured value telegram has been confirmed, the first measured value is
not output until after the configured number of scans. Therefore, there is always a time
delay equivalent to the number of scans configured for averaging. The digit of the first
scan included in the averaging calculation is always output in the scan counter. Invalid
distance values (= 0) are not included in the averaging calculation, so that in these
places a smaller number of scans is used in the division calculation.
Based on a scanning frequency of 15 Hz, a measured value is generated every 67 ms .
The time delay affecting data output results from this base value multiplied by the
number of averaging operations (e.g., 2 averagings = 134 ms, 10 averagings =670 ms).
