Position Description
10 Integrated illumination unit
1)
/
aiming laser
S: red left, blue right / aiming
laser
D: left IR
2)
, right IR
2)
/ aiming
laser
11 Parameter set
F: Full Feature Set for variant
InspectorP621
12 Focal length
B: 9.6 mm
F: 17, 1 mm
G: 17, 1 mm with visible block
filter
13 Connectivity package
B: Ethernet, serial, CAN, I/O,
USB, memory card slot
14 IP Protection class
5: IP 65
1)
Front view
2)
IR = Infrared light
NOTE
Not all combinations are possible according to the type code. The available device vari‐
ants can be found online at:
•
www.sick.com/InspectorP62x
3.2 Scope of delivery
The delivery of the device includes the following components:
Table 2: Scope of delivery
No. of
units
Component Comment
1 Device in the version ordered Without bracket and optional connecting cables.
1 Printed safety notes, multilin‐
gual
Brief information and general safety notes.
2 Sliding nut, 5.5 mm deep, with
M5 threaded fixing hole
Alternative mounting option for the device instead
of tapped blind hole. Use in pairs!
Associated components not contained in the delivery:
Table 3: Other components
Component Comment
SOPAS ET configuration software Available online at:
•
www.sick.com/SOPAS_ET
SICK AppStudio software Available online at:
•
www.sick.com/SICK_AppStudio
SICK AppManager software Available online at:
•
www.sick.com/SICK_AppManager
3 PRODUCT DESCRIPTION
14
O P E R A T I N G I N S T R U C T I O N S | InspectorP621 8024439//2019-06 | SICK
Subject to change without notice
