10.4 Process data structure
WTF12L/WTF12V A00
IO-Link V1.1
Process data 2bytes
Byte 0: Bits 15 ... 8
Byte 1: Bits 7 ... 0
Bit 0/data type Q
L1
/Boolean
Bit 1/data type Q
L2
/Boolean
Bit 2 ... 15/description / data type [empty]
11 Annex
11.1 Conformities and certificates
You can obtain declarations of conformity, certificates, and the current operating
instructions for the product at www.sick.com. To do so, enter the product part number
in the search field (part number: see the entry in the “P/N” or “Ident. no.” field on the
type label).
