Meldungen
7 Messages on the display
The data traffic via PROFINET is indicated with status LEDs on both RJ45 sockets.
The meaning is the same for both ports.
LED green
LED yellow
Meaning
off
off
 no power supply
 no network connection
on
ons
 network connection exists
on
flashing
 initialization phase
 application relation is set up
on
on
 application relation is established
If the connection can not be established or faults occur during operation the display shown the error
message ''. Possible causes are IP problems due to incorrect network parameters, multiple
device names, command of undefined properties or other fieldbus errors.
Once the connection has been established, the following messages can be displayed:
With a 4-digit display

Until the first time user data is received, the display shows a frame on its
display alternating with the above status messages.

The "PROFINET flashing" diagnostic function, which can be called from the
engineering tool, is signaled by three horizontal lines at each position.

Underflow: The value sent to the display can not be displayed on the display.
For example, the value '-1500' can not be displayed on a four-digit device.

Overflow: The value sent to the display can not be displayed on the display. For
example, the value '-26550' can not be displayed on a four-digit device.
