BAL S302 PFN RT 1.00 23/27
Technische
13 Technical data
Fieldbus
Interface PROFINET IO RT, conformance class CC-B
MAC address The MAC address for the PROFINET coupling is on the top side of the
device.
Integrated switch PROFINET IO IRT, conformance class CC-C
Power supply
The screw-type terminals for the power supply are located on the power supply unit in the bottom
section of the housing. They have the following designations:
Devices for a power supply 115 V AC or 230 V AC L, N and PE
Devices for a power supply 24 V DC +, – and PE
Housing colors
Case front RAL 5002ultramarine
Case rear part RAL 7035 light grey
Ambient conditions
Operating temperature 0…55 °C, with heating -20…55 °C
Storage temperature -30…85 °C
Relative humidity max. 95 % (non condensing)
Gerätreausführung
